Solar Panels

Name: Solar Panels
Brand: ROSOL ENERGY PVT. LTD.
Price: 16.5-30 INR
Availability: InStock

Price 16.5-30 INR/ Piece

Get a Price/Quote

MOQ : 10 Watts

Solar Panels Specification

Product Type
Solar Panels

Material
Polycrystalline Silicon

Number of Cells
72

Operating Temperature
-40C to +85C

Max Voltage
37.0 V

Max System Voltage
1000 V DC

Panel Efficiency
17.2%

Cable Length
1 meter

Number Of Diodes
3

Maximum Snow Load
5400 Pa

Size
Standard - 72 cell

Dimension (L*W*H)
1960 x 992 x 40 mm

Weight
22 kg

Color
Blue

Peak Power (Pmax)
320 W

Fire Rating
Class C

Wind Load
2400 Pa

Frame Material
Anodized Aluminum

Glass Thickness
3.2 mm

Junction Box Protection
IP67

Cell Type
Mono/Poly Silicon

Open Circuit Voltage (Voc)
45.2 V

Short Circuit Current (Isc)
9.15 A

Connector Type
MC4 Compatible

Current at Maximum Power (Imp)
8.65 A

Voltage at Maximum Power (Vmp)
37.0 V

Solar Panels Trade Information

Minimum Order Quantity
10 Watts

Supply Ability
5 Watts Per Day

Delivery Time
1 Week

Main Export Market(s)
Asia

Main Domestic Market
All India

About Solar Panels

Solar panels collect clean renewable energy in the form of sunlight and convert that light into electricity which can then be used to provide power for electrical loads. Monocrystalline and Polycrystalline both are available.

We have PAN India presence majorly in cities like Delhi NCR, Haryana, Uttar Pradesh, Punjab, Chandigarh, Pune, Uttrakhand, Goa, Karnataka, Bengaluru, Mumbai, Kolkata, Hyderabad, Chennai, Indore, Bhopal, Pune, Nashik, Kerala, West Bengal, Jharkhand, Assam, Odisha, Rajasthan, Jharkhand, Uttar Pradesh, Gujarat, Chattishgarh, Tamil Nadu, Himachal Pradesh, Madhya Pradesh, Bihar, Chandigarh etc

Optimized Performance for Indian Environments

Engineered for durability and performance, this 320W solar panel offers dependable power generation even in India's varied climates. With a fire rating of Class C and robust IP67 junction box protection, it resists dust, moisture, and environmental challenges. Its anodized aluminum frame and 3.2 mm toughened glass provide strong defense against high wind (2400 Pa) and snow loads (5400 Pa), ensuring long service life and safety for rooftop or ground-mounted solar systems.

Efficient and Easy-to-Install Solar Solution

With a 72-cell standard design, blue polycrystalline surface, and 17.2% efficiency, this panel optimizes space and output. The MC4 compatible connector and included 1-meter cable streamline installation, while the three integrated bypass diodes enhance performance in shaded conditions. Application versatility and reliable construction make it suitable for residential, commercial, or industrial uses throughout India.

FAQ's of Solar Panels:

Q: How does the 320W solar panel perform under extreme weather conditions?

A: Designed with a robust anodized aluminum frame and 3.2 mm toughened glass, the panel can endure wind loads up to 2400 Pa and snow loads up to 5400 Pa. Its IP67-rated junction box also protects against dust and moisture, ensuring consistent performance from -40C to +85C.

Q: What is the installation process for this solar panel?

A: The panel is equipped with MC4 compatible connectors and a 1-meter cable, which simplifies installation for installers. The standard 72-cell format and manageable weight (22 kg) make it suitable for rooftop and ground-mounted systems, allowing for secure and quick connections to existing solar infrastructure.

Q: When should I consider using polycrystalline versus monocrystalline silicon panels?

A: Monocrystalline panels offer slightly higher efficiencies and perform better in low-light or high-temperature conditions, while polycrystalline panels like this one provide excellent value and solid reliability. Your choice depends on budget, available space, and specific energy needs.

Q: Where can this solar panel be installed?

A: Thanks to its robust build and weather resistance, the panel is suitable for installation in urban, rural, and industrial settings across India. It is ideal for rooftops, solar farms, and even off-grid applications that demand dependable and durable energy solutions.

Q: What benefits does this solar panel offer over lower-power alternatives?

A: With a peak power output of 320W and 17.2% efficiency, you can generate more energy per panel, reducing installation space and improving overall system output. This efficiency is especially beneficial in areas with limited space or where maximizing output per square meter is a priority.

Q: How does the panel's junction box protection (IP67) enhance reliability?

A: The IP67-rated junction box protects the internal components from dust ingress and immersion in water up to 1 meter, ensuring long-term, trouble-free operation in humid or rainy conditions. This helps maintain power output and reduces the risk of failures.
